Vue 使用 bpmn.js 流程图添加高亮节点展示

当 Vue.js 与 bpmn.js 相结合时，我们能够构建出功能强大的流程图编辑器，还能够为流程图添加各种交互功能，如高亮节点展示。高亮节点功能在流程图中具有重要意义，它可以帮助用户快速定位到关键节点，从而更好地理解和分析流程。

在本文中，小编将演示如何在 Vue 中使用 bpmn.js 实现流程图的高亮节点展示功能。

完整组件代码

<template>
	<div class="containers">
		<div class="canvas" ref="canvas" style="height: 60vh;background: white"></div>
	</div>
</template>

<script>
// 引入自定义 Viewer
import { modelView } from '@/api/maintain'
import { CustomViewer } from '@/utils/custom-bpmn'

export default {
	name: "bpmnViewer",
	mounted() {
		this.init();
	},
	props: ['xmlID'],
	data() {
		return {
			bpmnData: null,
			bpmnViewer: null,
			container: null,
			ledValue: null,
			canvas: null,
			flows: null
		};
	},
	methods: {
		init() {
			const canvas = this.$refs.canvas
			this.bpmnViewer = new CustomViewer({
				container: canvas
			})
			this.createNewDiagram()
		},
                // 设计高亮节点class
		setClass() {
			for (let i = 0; i < this.ledValue.length; i++) {
				console.log('this.ledValue', this.ledValue);
				const elm11 = document.querySelectorAll(`[data-element-id="${this.ledValue[i].id}"]`)[0]
				console.log('elm11', elm11);
				elm11.classList.add('new-class');
			}
		},
		async createNewDiagram() {
			try {
				// 本地 .bpmn 文件地址
				await modelView({ tableGuid: this.xmlID }).then(res => {

					if (res.data.flow) {
						this.flows = []
						res.data.flow.forEach(f => {
							const { endTime } = f
							const ff = {
								id: f.historyActivityId,
								class: !endTime && f.historyActivityType !== 'candidate' ? 'nodePrimary' : ''
							}
							if (f.historyActivityType === 'sequenceFlow') ff.class = 'lineWarn'
							else if (!ff.class && f.historyActivityType !== 'candidate') ff.class = 'nodeSuccess'

							const index = this.flows.findIndex(fl => fl.id === f.historyActivityId)
							if (index !== -1) this.flows.splice(index, 1, ff)
							else this.flows.push(ff)
						})
						this.ledValue = this.flows
					}
					console.log("this.ledValue", this.ledValue);
					this.bpmnViewer.importXML(res.data.xml)
					this.setClass()
				})
			} catch (err) {
				console.log("无效", err.message, err.warnings);
				this.setClass()
			}
		}
	}
};
</script>

CSS 部分

<style lang="scss" scoped>
:deep() {
	// 高亮节点
	.new-class {
		.djs-visual {
			circle {
				fill: #67c23a !important;
			}

			rect {
				fill: #67c23a !important;
			}
		}
	}
	// 隐藏水印
	.bjs-powered-by {
		display: none;
	}
}
</style>
